DATEL CMOS閃存A/D轉換器
發布時間：2021-04-01 17:14:27 瀏覽：1148
超高速A/D轉換器是信號分析處理操作系統的關鍵構成部分。廣泛運用于雷達探測、高速寬帶數字接收器和高速硬盤。符合各種性能指標要求的超高速A/D轉換器的設計方案成為了這類操作系統的重中之重和難點?，F(xiàn)階段，基本上所有的采樣率在1GHz以上的超高速A/D轉換器都選用并行相對比較結構。這類A/D轉換器具備采樣率高、操作系統簡單等特點。它是最常見的高速低分辨率（8位以下）結構特征。在并行相對比較結構特征中，最重要的零部件是并行比較器。其性能指標直接關系到操作系統的速度、分辨率、面積積和功耗，是整個A/D轉換器設計方案的重中之重。
DATEL閃光轉換器特征：
真閃光ADC
無延遲
邊緣觸發轉換
適用于突發模式應用領域
易于在多通道應用領域中使用
連續模式應用領域
可配備輸入?yún)^(qū)域
深圳市立維創展科技有限公司，優勢提供DATEL產品渠道，歡迎咨詢。
詳情了解DATEL請點擊：/brand/66.html
或聯系我們的銷售工程師：0755- 83642657 QQ： 2295048674
 Part Number
| Resolution | Sampling Rate | Power Consumption | Package Type | Operating Temp. Range (min) | Operating Temp. Range (max) | RoHS |
ADC-207LC | 7 Bit | 20 MHz | 0.25 W | CLCC | 0 oC | +70 oC | No |
ADC-207LC-C | 7 Bit | 20 MHz | 0.25 W | CLCC | 0 oC | +70 oC | Yes |
ADC-207LE | 7 Bit | 20 MHz | 0.25 W | CLCC | -40 oC | +100 oC | No |
ADC-207LE-C | 7 Bit | 20 MHz | 0.25 W | CLCC | -40 oC | +100 oC | Yes |
ADC-207LM | 7 Bit | 20 MHz | 0.25 W | CLCC | -55 oC | +125 oC | No |
ADC-207LM-C | 7 Bit | 20 MHz | 0.25 W | CLCC | -55 oC | +125 oC | Yes |
ADC-207LM-QL | 7 Bit | 20 MHz | 0.25 W | CLCC | -55 oC | +125 oC | No |
ADC-207LM-QL-C | 7 Bit | 20 MHz | 0.25 W | CLCC | -55 oC | +125 oC | Yes |
ADC-207MC | 7 Bit | 20 MHz | 0.25 W | DIP | 0 oC | +70 oC | No |
ADC-207MC-C | 7 Bit | 20 MHz | 0.25 W | DIP | 0 oC | +70 oC | Yes |
ADC-207ME | 7 Bit | 20 MHz | 0.25 W | DIP | -40 oC | +100 oC | No |
ADC-207ME-C | 7 Bit | 20 MHz | 0.25 W | DIP | -40 oC | +100 oC | Yes |
ADC-207MM | 7 Bit | 20 MHz | 0.25 W | DIP | -55 oC | +125 oC | No |
ADC-207MM-C | 7 Bit | 20 MHz | 0.25 W | DIP | -55 oC | +125 oC | Yes |
ADC-207MM-QL | 7 Bit | 20 MHz | 0.25 W | DIP | -55 oC | +125 oC | No |
ADC-207MM-QL-C | 7 Bit | 20 MHz | 0.25 W | CLCC | -55 oC | +125 oC | Yes |
ADC-208ALC | 8 Bit | 20 MHz | 0.25 W | CLCC | 0 oC | +70 oC | No |
ADC-208ALC-C | 8 Bit | 20 MHz | 0.225 W | CLCC | 0 oC | +70 oC | Yes |
ADC-208ALE | 8 Bit | 20 MHz | 0.25 W | DDIP | -40 oC | +100 oC | No |
ADC-208ALE-C | 8 Bit | 20 MHz | 0.25 W | DDIP | -40 oC | +100 oC | Yes |
ADC-208ALM | 8 Bit | 20 MHz | 0.25 W | CLCC | -55 oC | +125 oC | No |
ADC-208ALM-C | 8 Bit | 20 MHz | 0.225 W | CLCC | -55 oC | +125 oC | Yes |
ADC-208AMC | 8 Bit | 20 MHz | 0.25 W | DDIP | 0 oC | +70 oC | No |
ADC-208AMC-C | 8 Bit | 20 MHz | 0.225 W | DDIP | 0 oC | +70 oC | Yes |
ADC-208AME | 8 Bit | 20 MHz | 0.25 W | DDIP | -40 oC | +100 oC | No |
ADC-208AME-C | 8 Bit | 20 MHz | 0.25 W | DDIP | -40 oC | +100 oC | Yes |
ADC-208AMM | 8 Bit | 20 MHz | 0.25 W | DDIP | -55 oC | +125 oC | No |
ADC-208AMM-C | 8 Bit | 20 MHz | 0.225 W | DDIP | -55 oC | +125 oC | Yes |
ADC-208AMM-QL | 8 Bit | 20 MHz | 0.25 W | DDIP | -55 oC | +125 oC | No |
ADC-208AMM-QL-C | 8 Bit | 20 MHz | 0.225 W | DDIP | -55 oC | +125 oC | Yes |
ADC-228A/883 | 8 Bit | 20 MHz | 0.9 W | DDIP | -55 oC | +125 oC | No |
ADC-228AMC | 8 Bit | 20 MHz | 0.9 W | DDIP | 0 oC | +70 oC | No |
ADC-228AMC-C | 8 Bit | 20 MHz | 0.9 W | DDIP | 0 oC | +70 oC | Yes |
ADC-228AMM | 8 Bit | 20 MHz | 0.9 W | DDIP | -55 oC | +125 oC | No |
ADC-228AMM-C | 8 Bit | 20 MHz | 0.9 W | DDIP | -55 oC | +125 oC | Yes |
ADC-674A/883 | 12 Bit | 0.125 MHz | 0.25 W | DDIP | -55 oC | +125 oC | No |
ADC-674A/883-C | 12 Bit | 0.125 MHz | 0.25 W | DDIP | -55 oC | +125 oC | Yes |
ADC-674AMC | 12 Bit | 0.125 MHz | 0.25 W | DDIP | 0 oC | +70 oC | No |
ADC-674AMC-C | 12 Bit | 0.125 MHz | 0.25 W | DDIP | 0 oC | +70 oC | Yes |
ADC-674AME | 12 Bit | 0.125 MHz | 0.25 W | DDIP | -40 oC | +100 oC | No |
ADC-674AME-C | 12 Bit | 0.125 MHz | 0.25 W | DDIP | -40 oC | +100 oC | Yes |
ADC-674AMM | 12 Bit | 0.125 MHz | 0.25 W | DDIP | -55 oC | +125 oC | No |
ADC-674AMM-C | 12 Bit | 0.125 MHz | 0.25 W | DDIP | -55 oC | +125 oC | Yes |
ADC-674L/883 | 12 Bit | 0.125 MHz | 0.25 W | LCC | -55 oC | +125 oC | No |
ADC-674LC | 12 Bit | 0.125 MHz | 0.25 W | LCC | 0 oC | +70 oC | No |
ADC-674L-C/883 | 12 Bit | 0.125 MHz | 0.25 W | LCC | -55 oC | +125 oC | Yes |
ADC-674LC-C | 12 Bit | 0.125 MHz | 0.25 W | LCC | 0 oC | +70 oC | Yes |
ADC-674LE | 12 Bit | 0.125 MHz | 0.25 W | LCC | -40 oC | +100 oC | No |
ADC-674LE-C | 12 Bit | 0.125 MHz | 0.25 W | LCC | -40 oC | +100 oC | Yes |
ADC-674LM | 12 Bit | 0.125 MHz | 0.25 W | LCC | -55 oC | +125 oC | No |
ADC-674LM-C | 12 Bit | 0.125 MHz | 0.25 W | LCC | -55 oC | +125 oC | Yes |
